DS1102E

100MHz, 2CH, 1GSa/s

SKU: DS1000E/U Category: Tags: , ,

DS1000E series are the high-performance, economic digital oscilloscopes. They are widely used in the areas of education, training, production line, research and development.

Dual analog channels and 16 channels logic analyzer, 100MHz maximum bandwidth,1GSa/s maximum real-time sample rate and 25GSa/s maximum equivalent sample rate
5.6 inch 64k TFT LCD makes the waveform displays more clear and vivid
Abundant trigger types: Edge, Pulse Width,Video, Slope, Alternate, Pattern and Duration
Unique adjustable trigger sensitivity enablesto meet different demands
Enable to measure 22 types of waveparameters and track measurements via cursor automatically
Unique waveform record and replay function
Fine delayed scan function
Built-in FFT function, hold practical digital filters
